SPECIFICATION
Accuracy | 1% |
Power supply | DC8-36V or AC85-264V |
Power consumption | 1.5KW |
Flow rate | 0~±10m/s |
Pipe inner diameter | 15-6000mm |
Output signal | 4-20mA, OTC pulse, relay |
Data interface | MODBUS protocol/RS485 |
Integrated installation principle of ultrasonic level gauge
1. The distance from the emitting surface of the sensor to the
lowest liquid level should be less than the measuring range of the
selected instrument.
2. The distance from the emitting surface of the sensor to the
highest liquid level should be greater than the blind zone of the
selection and purchase of the instrument.
3. The emitting surface of the sensor should be parallel to the
liquid surface.
4. The installation position of the sensor should avoid the
fluctuation of the liquid level as much as possible, such as the
water inlet and outlet.
5. If the pool or tank wall is not smooth, the instrument should
keep the pool or tank wall above 0.3m.
6. If the distance from the transmitter surface of the sensor to
the highest liquid level is less than the blind zone of the
selected instrument, a telescopic tube should be installed, the
diameter of which is greater than 120 mm, the length is 0.35m ≤
0.50m, the vertical installation, the inner wall is smooth, and the
inner hole of the tank should be Greater than the inner diameter of
the extension tube. Or the pipe can be directly connected to the
bottom of the tank, the pipe diameter is greater than 80 mm, and
the hole at the bottom of the pipe can easily flow into liquid.
